# ArcSmith Editor API Integration Skill

Use this skill to interface with the local REST API server exposed by the running ArcSmith desktop Tauri application.

## 1. Server Metadata & Setup
- **Base URL:** http://127.0.0.1:14230
- **Authentication:** Zero-configuration (no keys or tokens required — binds strictly to loopback).
- **Schema Discovery:** GET /api/schema returns all endpoints at runtime.

## 2. CORS Policy
- GET / OPTIONS: Access-Control-Allow-Origin: * (read-only, safe to expose)
- POST / PATCH / DELETE: Access-Control-Allow-Origin: null (blocks cross-origin browser requests; curl/Python/Node.js unaffected)

## 3. API Endpoints

### Health
- **GET /health** — Returns {"status":"ok","version":"1.0.1","service":"ArcSmith"}
- **GET /api/schema** — Machine-readable endpoint listing

### Narrative Project
- **GET /api/project** — Fetch the full project JSON. Waits up to 2s for startup sync.
- **POST /api/project** — Replace the entire project state. Body: application/json.

### Sub-Resources CRUD
:resource = characters | environments | variables | scenes | nodes | connections
- **GET /api/:resource** — List all items (returns {} or [] if key absent, never 500).
- **POST /api/:resource** — Create/upsert item. ID auto-generated if omitted. Injects default fields.
- **GET /api/:resource/:id** — Fetch single item or 404.
- **PATCH /api/:resource/:id** — Shallow-merge partial fields onto existing item. Body: application/json.
- **DELETE /api/:resource/:id** — Remove item with full cascade cleanup.
  - Cannot delete the last scene (returns 409 Conflict).
  - Scenes: clears entryNodeId + resets activeSceneId to first remaining scene.

### Editor Action Commands
- **GET /api/actions** — Returns {"allowed_actions": [...]}
- **POST /api/actions** — Triggers an editor operation:
    - {"action": "undo"} -> Revert last change (Ctrl+Z)
    - {"action": "redo"} -> Re-apply last change (Ctrl+Y)
    - {"action": "new_project"} -> Reset to clean canvas
    - {"action": "select_node", "payload": {"nodeId": "id" | null}} -> Highlight node
    - {"action": "set_active_scene", "payload": {"sceneId": "id"}} -> Switch scene tab
  - Unknown action names return 400 with the allowed list.

## 4. Data Schemas (Sub-Resources)
- **Character:** {"id": string, "name": string, "portraits": string[], "customProperties"?: object}
- **Environment:** {"id": string, "name": string, "description": string, "imagePath"?: string, "customProperties"?: object}
- **Variable:** {"id": string, "name": string, "type": "bool"|"int"|"str", "value": any}
- **Scene:** {"id": string, "name": string, "color": string}
- **ArcNode:** {"id": string, "type": "dialogue"|"monologue"|"hub"|"condition"|"set"|"jump", "x": number, "y": number, "sceneId": string, "data": object}
  - type, x, y, sceneId are REQUIRED for POST — returns 422 if missing.
- **ArcConnection:** {"id": string, "fromNode": string, "fromSlot": string, "toNode": string, "toSlot": string}

## 5. HTTP Status Codes Used
- 200 OK — Success
- 400 Bad Request — Malformed JSON or bad field values
- 404 Not Found — Resource or ID not found
- 405 Method Not Allowed — Includes Allow header (RFC 7231)
- 409 Conflict — Cannot delete last scene
- 413 Content Too Large — Body exceeds 20 MB
- 415 Unsupported Media Type — Missing Content-Type: application/json
- 422 Unprocessable Entity — Valid JSON but missing required node fields
- 500 Internal Server Error — Mutex poisoned or serialisation failure
- 503 Service Unavailable — Too many concurrent connections (limit: 32)

curl http://localhost:14230/api/project

const res = await fetch('http://localhost:14230/api/project');
const project = await res.json();
console.log(project);

Invoke-RestMethod -Uri http://localhost:14230/api/project

curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"title":"My Story","description":"","entryNodeId":null,"characters":{},"environments":{},"variables":{},"scenes":{},"nodes":{},"connections":[],"assets":[]}' \
  http://localhost:14230/api/project

const payload = {
  title: "My Story",
  description: "",
  entryNodeId: null,
  characters: {},
  environments: {},
  variables: {},
  scenes: {},
  nodes: {},
  connections: [],
  assets: []
};

const res = await fetch('http://localhost:14230/api/project', {
  method: 'POST',
  headers: { 'Content-Type': 'application/json' },
  body: JSON.stringify(payload)
});

Invoke-RestMethod -Uri http://localhost:14230/api/project -Method Post -Body '{"title":"My Story","description":"","entryNodeId":null,"characters":{},"environments":{},"variables":{},"scenes":{},"nodes":{},"connections":[],"assets":[]}' -ContentType "application/json"

curl http://localhost:14230/api/characters

const res = await fetch('http://localhost:14230/api/characters');
const characters = await res.json();
console.log(characters);

Invoke-RestMethod -Uri http://localhost:14230/api/characters

curl http://localhost:14230/api/characters/18bc7557258d3cec

const res = await fetch('http://localhost:14230/api/characters/18bc7557258d3cec');
const character = await res.json();
console.log(character);

Invoke-RestMethod -Uri http://localhost:14230/api/characters/18bc7557258d3cec

curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"name":"Alistair","portraits":["pose1.png"]}' \
  http://localhost:14230/api/characters

const characterData = {
  name: "Alistair",
  portraits: ["pose1.png"]
};

const res = await fetch('http://localhost:14230/api/characters', {
  method: 'POST',
  headers: { 'Content-Type': 'application/json' },
  body: JSON.stringify(characterData)
});

Invoke-RestMethod -Uri http://localhost:14230/api/characters -Method Post -Body '{"name":"Alistair","portraits":["pose1.png"]}' -ContentType "application/json"

curl -X PATCH \
  -H "Content-Type: application/json" \
  -d '{"name":"Alistair Thorne"}' \
  http://localhost:14230/api/characters/18bc7557258d3cec

// Only updates the 'name' field — all other fields unchanged
const res = await fetch('http://localhost:14230/api/characters/18bc7557258d3cec', {
  method: 'PATCH',
  headers: { 'Content-Type': 'application/json' },
  body: JSON.stringify({ name: "Alistair Thorne" })
});
const updated = await res.json();

Invoke-RestMethod -Uri http://localhost:14230/api/characters/18bc7557258d3cec -Method Patch -Body '{"name":"Alistair Thorne"}' -ContentType "application/json"

curl -X DELETE http://localhost:14230/api/characters/18bc7557258d3cec

const res = await fetch('http://localhost:14230/api/characters/18bc7557258d3cec', {
  method: 'DELETE'
});

Invoke-RestMethod -Uri http://localhost:14230/api/characters/18bc7557258d3cec -Method Delete

{
  "allowed_actions": [
    "undo", "redo", "new_project", "select_node", "set_active_scene"
  ]
}

curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"action":"undo"}' \
  http://localhost:14230/api/actions

const payload = {
  action: "select_node",
  payload: { nodeId: "18bc7557258d3cec" }
};

const res = await fetch('http://localhost:14230/api/actions', {
  method: 'POST',
  headers: { 'Content-Type': 'application/json' },
  body: JSON.stringify(payload)
});

Invoke-RestMethod -Uri http://localhost:14230/api/actions -Method Post -Body '{"action":"undo"}' -ContentType "application/json"

{
  "status": "error",
  "message": "Unknown action 'fly_away'. See allowed_actions.",
  "allowed_actions": ["undo", "redo", "new_project", "select_node", "set_active_scene"]
}

curl http://localhost:14230/api/schema

const res = await fetch('http://localhost:14230/api/schema');
const schema = await res.json();
console.log(schema.endpoints);

Invoke-RestMethod -Uri http://localhost:14230/api/schema
